FE3D32N / 35N / 40N Series 3-Wheel Dual AC Drive Electric Forklift
The FE3D32N/35N/40N Series is a 3-wheel pneumatic Dual AC Drive electric forklift with 3,200 / 3,500 / 4,000 lb capacities. Features 48V fully AC drive with all-around dual AC front-wheel drive, Curtis intelligent control, on-demand fully hydrostatic power steering, wet disc brakes, side shift, full suspension seat, and 48V lead-acid battery standard with three optional lithium upgrades. 3-Year Chassis Limited Warranty + 10-Year Limited Warranty on optional Lithium Battery.
- 3 configurations available
- Factory-direct from authorized Noblelift dealer
Configured for your application. Volume discounts and Net-30 available.
1. Choose your model
At a Glance
About This Equipment
Overview
The FE3D32N/35N/40N Series Dual AC Drive Forklift is Noblelift flagship 3-wheel pneumatic-tire electric forklift with all-around dual AC front-wheel drive and capacities from 3,200 to 4,000 lb. Lead-acid battery standard, three lithium upgrade tiers available.
Three-Wheel Pneumatic Design
Solid Pneumatic Tires for indoor/outdoor mixed-surface operation
3-wheel layout - tighter turning than 4-wheel competitors
All-Around Dual AC Front Wheel Drive - both front wheels driven independently
48V architecture - same voltage class as 4,000+ lb 4-wheel forklifts
Model Variants
FE3D32N - 3,200 lb, 6,732 lb service weight, Quote
FE3D35N - 3,500 lb, 6,952 lb service weight, Quote
FE3D40N - 4,000 lb, 7,524 lb service weight, Quote
Curtis Drivetrain & Controls
Curtis Intelligent Computer Control with adjustable performance parameters
48V Fully AC drive with regenerative braking
All-Around Dual AC Front Wheel Drive
AC Hydraulic Pump & Power Steering Motor
IMS Display Indicators with on-board self-diagnostics
4-Way Proportional Hydraulic Control Valve standard
On-Demand Fully Hydrostatic Power Steering (FHPS)
Battery Discharge Indicator (BDI) with lift interrupt
Mast Options
Standard 118" 2-stage included. Seven optional masts: 118" 2-stage FFV (+Quote), 157" 3-stage FFV (+Quote), 171" 3-stage FFV (+Quote), 177" 3-stage FFV (+Quote), 189" 3-stage FFV (+Quote), 197" 3-stage FFV (+Quote), 217" 3-stage FFV (+Quote).
Battery & Charger
Standard 48V lead-acid: 455Ah on FE3D32N/35N + 48V/65A 3-phase charger; 560Ah on FE3D40N + 48V/80A 3-phase charger. Three lithium upgrades available: 48V/300Ah (+Quote), 48V/400Ah (+Quote), 48V/554Ah (+Quote). European REMA Connector (95044-01). Lithium upgrade carries 10-Year Limited Battery Warranty.
Additional Options
Lithium Battery Wrap for Colder Temperatures +Quote
Cascade Side Shifting Fork Positioner +Quote
Operator Comfort & Safety
Operator Presence Sensing System
Operator Restraint System with retractable seat belt
Full / Deluxe Suspension Seat
Tilt Steering Column + small spinner-knob steering wheel
Rear Grab Bar with Horn + USB Connector
Side Shift standard
Wet Disc Brakes - sealed, oil-cooled, low-maintenance
48" High Load Back Rest prevents tip-back
OHG Headlights, Blue Light, Rear Work Light, dual rearview mirrors
IPX4 Water Resistance Design
Standard Configuration
118" 2-Stage mast, 42" forks, 24" load center, 5°F/7°B tilt, 48V Fully AC + Dual AC FWD, side shift, full suspension seat, wet disc brakes, OAL height 79", solid pneumatic drive 18×7-8 (32N/35N) or 200×50-10 (40N), steer 15×4½-8, IPX4.
Warranty & Support
3-Year Limited Warranty on chassis, drivetrain and electrical. 10-Year Limited Warranty on optional lithium battery. Extended service plans, on-site training, and field support available through PHS Lift dealer network.
Full Specifications
| Standard Fork Length | 42 in |
| Voltage | 48V |
| Fuel Type | Electric (Lead-Acid Standard, Lithium Optional) |
| Battery (FE3D32N/35N Standard) | 48V / 455Ah Lead-Acid |
| Battery (FE3D40N Standard) | 48V / 560Ah Lead-Acid |
| Charger (FE3D32N/35N Standard) | 48V / 65A 208-240V or 480V 3-Phase |
| Charger (FE3D40N Standard) | 48V / 80A 208-240V or 480V 3-Phase |
| Warranty (Lithium Battery, optional) | 10-Year Limited |
